The Teknologg LP-100 RTD data loggers are low power battery operated devices are used for reading resistance temperature probes.
Features:
- High Accuracy
- Battery Operation
- 24 Bit ADC
- Low Noise
- Internal Memory with External Micro SD support
- USB Interface
- Recording Up to 100 Hz
- Programmable High and Low Alarms
- Real Time Data View in Software
The Teknologg LP-100 RTD data loggers are low power battery operated devices are used for reading resistance temperature probes.
Depending on device model pt100/pt1000 probes can be directly interfaced to data logger.
Stored values can be transferred to pc via USB port and Daloco software. Device configuration, reading real values and live charting can be done by easy to use Daloco software.
RTD Characteristic
RTD Support PT100,PT1000
2-3-4 wire connection
Please Refer to ordering information
Resolution 0.01 °C
Accuracy 0.3°C @ pt100
0.1°C @ pt1000
Noise Rejection Simultaneous 50 Hz/60 Hz
General Parameters:
Measure Time | 0.01 seconds ~ 24 hours (configured by software) |
Battery | 3xAA Alkaline |
Memory | Internal:140000 Records External micro SD support up to 32GB |
Logging Time Interval | 1 seconds ~ 24 hours (configured by software) |
Interface | Mini USB-B Port |
Working Temperature | -30 ~ 80°C Not for use in condensing conditions |
Dimensions | 100x68x22mm |
LP-100.1y.x RTD Data Logger User Manual
Product No. | Details |
---|---|
LP-100.10.x | Data Logger Input Type: PT100 Probe |
LP-100.11.x | Data Logger Input Type: PT1000 Probe |
LP-100.1y.0 | Data Logger with 3xAA Alkaline Battery |
LP-100.1y.1 | Battery not shipped with device |
